Eaton XCEL45-100 402-1112-00
Discover the Eaton XCEL45-100 402-1112-00, a compact and economical low-speed, high-torque (LSHT) hydraulic motor. Features a 45 cm³/r displacement, 2-bolt mount, and 1-inch straight keyed shaft, ideal for various industrial and mobile applications.
Eaton XCEL45-100 402-1112-00
The Eaton XCEL45-100, with part number 402-1112-00, is a highly reliable and economical low-speed, high-torque (LSHT) hydraulic motor. As part of the XCEL series, it is engineered to provide a cost-effective solution for light to medium-duty applications without compromising on performance. This compact motor features an industry-proven spool valve design and gerotor/geroler power element, ensuring smooth performance, high efficiency, and extended service life. It is an excellent choice for various industrial and mobile machinery, including agricultural equipment, conveyors, machine tools, and food processing equipment.
Technical Specifications:
- Model Series: XCEL45-100
- Part Number: 402-1112-002
- Displacement: 45 cm³/r (2.75 in³/r)
- Mounting: 2-Bolt Flange, 82.6 mm (3.25 in) Pilot Diameter
- Shaft: 25.4 mm (1.00 in) Straight with Straight Key
- Ports: G 1/2 Main Ports, G 1/4 Case Drain Port
- Max Continuous Pressure: 125 bar (1800 psi)
- Max Continuous Torque: 79 Nm (700 lb-in)
| Brand | EATON |
|---|---|
| Model | XCEL45-100 402-1112-00 |
