Kofon SPL120-5
Discover the Kofon SPL120-5, a high-precision planetary gearbox with a 5:1 ratio and low backlash (≤3 arcmin). Ideal for servo motor applications requiring high torque and accuracy in robotics and automation.
Kofon SPL120-5 Planetary Gearbox
The Kofon SPL120-5 is a high-precision, low-backlash planetary gearbox designed for demanding servo applications. It features a compact, robust design with an inline configuration, ensuring high torsional stiffness and torque capacity. Engineered for superior performance and reliability, the SPL series is ideal for dynamic and precise motion control systems, including robotics, automation, CNC machinery, and packaging equipment. Its high-efficiency operation (≥97%) and low-noise performance make it a premier choice for integrating with a wide range of servo motors to achieve optimal system dynamics.
Technical Specifications:
- Model: SPL120-5
- Gear Ratio: 5:1
- Frame Size: 120 mm
- Standard Backlash: ≤ 3 arcmin
- Rated Output Torque: 190 Nm
- Max. Acceleration Torque: 380 Nm
- Torsional Rigidity: 20 Nm/arcmin
- Efficiency: ≥ 97%
- Protection Class: IP65
| Brand | Kofon |
|---|---|
| Model | SPL120-5 |
