OMRON E5CC-QX2ASM-802 Temperature Controller
The OMRON E5CC-QX2ASM-802 is a versatile and compact digital temperature controller, part of the E5CC series known for its ease of use and high performance. Measuring just 48×48 mm (1/16 DIN), it features a large, high-contrast white PV (Process Value) display for excellent readability. This model offers precise PID control (including auto-tuning) or ON/OFF control, suitable for a wide range of industrial heating and cooling applications. It accepts universal inputs (thermocouple, RTD, analog) and provides a voltage output for driving Solid State Relays (SSRs), two auxiliary relay outputs, event inputs, and RS-485 communication capabilities, making it a flexible solution for process control and monitoring.
Technical Specifications:
- Supply Voltage: 100 to 240 VAC, 50/60 Hz
- Size: 48 x 48 mm (1/16 DIN)
- Control Output 1: Voltage Output (for SSR drive), 12 VDC (PNP), 21 mA max.
- Auxiliary Outputs: 2 Relay Outputs (SPST-NO, 250 VAC, 3A resistive load)
- Input Type: Universal (Thermocouple, Pt100/JPt100 RTD, Analog Current/Voltage – Selectable)
- Control Method: ON/OFF or 2-PID control (with auto-tuning)
- Display: Dual 4-digit, 11-segment LCD (PV: White, SV: Green)
- Sampling Period: 50 ms
- Option Slot Features: 2 Event Inputs, RS-485 Communication
- Terminal Type: Screw Terminals
- Mounting: Panel Mount
- Operating Temperature: -10 to +55°C (14 to 131°F)
- Ingress Protection: IP66 (Front Panel, when panel mounted with gasket)
| Brand | OMRON |
|---|---|
| Model | E5CC-QX2ASM-802 |
