Rexroth R900770685 DBW 10 A1-5X/350-6EG24N9K4
Type:Rexroth R900770685 DBW 10 A1-5X/350-6EG24N9K4
Rexroth R900770685 DBW 10 A1-5X/350-6EG24N9K4
The Rexroth R900770685 DBW 10 A1-5X/350-6EG24N9K4 is a pilot-operated pressure relief valve designed to limit the pressure within a hydraulic system. This model features a solenoid-actuated unloading or pressure selection function, enabling remote control over system pressure. It is engineered for subplate mounting in accordance with ISO 6264 standards and is commonly employed in a variety of industrial hydraulic applications to protect system components from overpressure and to ensure precise pressure regulation. Its robust construction guarantees reliable operation and consistent performance under demanding conditions.
Technical Specifications:
- Valve Type: Pilot-operated pressure relief valve
- Model Series: DBW
- Size: NG10 (Nominal Size 10)
- Mounting Interface: Subplate mounting, porting pattern according to ISO 6264-AR-06-2-A
- Component Series: 5X
- Maximum Pressure Setting: 350 bar
- Solenoid Actuation: Yes, for unloading or pressure selection (Type 6E pilot valve)
- Solenoid Voltage: 24V DC (G24)
- Electrical Connection: Individual connector DIN EN 175301-803 (Type K4)
- Manual Override: Concealed manual override (N9)
- Pilot Control Valve: Directional spool valve, spring-centered, with 2 switching positions and 1 solenoid
- Hydraulic Fluid Compatibility: Mineral oil (HL, HLP) to DIN 51524; other fluids on request
- Maximum Flow: (Refer to datasheet for specific flow rates at pressure settings)
| Brand | Rexroth |
|---|---|
| Model | R900770685 DBW 10 A1-5X/350-6EG24N9K4 |
