Rexroth R900949749 4WRZE10W8-50-7X/6EG24N9EK31/F1D3V
Type:Rexroth R900949749 4WRZE10W8-50-7X/6EG24N9EK31/F1D3V
Rexroth R900949749 4WRZE10W8-50-7X/6EG24N9EK31/F1D3V
The Rexroth R900949749, model 4WRZE10W8-50-7X/6EG24N9EK31/F1D3V, is a high-response, pilot-operated proportional directional valve. It features integrated on-board electronics (OBE) for precise closed-loop control and electrical position feedback of the main spool. This NG10 (CETOP 05) valve is engineered to manage flow direction and magnitude up to 50 L/min. The “W8” spool configuration ensures specific flow paths, typically with a closed center in the de-energized state, while the “F1” designation provides a failsafe mechanism, returning the spool to a P-to-T flow path in its central position upon power loss or critical fault. Operating on a 24V DC supply and equipped with NBR seals, it is well-suited for demanding industrial hydraulic systems using mineral oil-based fluids.
Technical Specifications:
- Product Type: Pilot-operated proportional directional control valve with integrated electronics (OBE) and electrical position feedback
- Model Code: 4WRZE10W8-50-7X/6EG24N9EK31/F1D3V
- Nominal Size: NG10 (according to ISO 4401-05-04-0-05, CETOP 05)
- Spool Symbol: W8 (3-position, 4-way, specific flow paths, typically closed center)
- Maximum Operating Pressure (Ports P, A, B): 315 bar (4568 psi)
- Maximum Operating Pressure (Port T – Tank): 210 bar (3045 psi)
- Nominal Flow Rate: 50 L/min (at 10 bar Δp per control land)
- Component Series: 7X
- Actuation: Proportional solenoid with On-Board Electronics (OBE)
- Supply Voltage (OBE): 24V DC
- Electrical Connection (OBE Signal – K31): Connector according to DIN EN 175201-804, 4-pole + PE
- Command Value Input (Interface A1): ±10 V
- Actual Value Output (Interface A1): ±10 V
- Failsafe Position (F1): Spool in central position (P → T) upon power failure or cable break in feedback sensor
- Seal Material (D3): NBR (Nitrile Butadiene Rubber)
- Permissible Hydraulic Fluid: Mineral oil (HL, HLP) according to DIN 51524
- Fluid Temperature Range: -20°C to +80°C (with NBR seals)
| Brand | Rexroth |
|---|---|
| Model | R900949749 4WRZE10W8-50-7X/6EG24N9EK31/F1D3V |
